Custom Segment LCD Display

Availability:In Stock

Manufacturer	SINDA
Part Number	SDGB12864-01
Display Format	128x64 dots
Interface	8-bit Parallel
IC or Equivalent	AIP310107 SBN0064
Connection	Pin Header
Outline Dimension	54.00(W)x50.00(H)x8.00(T)mm
Visual Area	43.50x29.00mm
Active Area	40.92x20.92mm
Dot (Pixel) Size	0.28x0.35mm
Dot (Pixel) Pitch	0.32x0.39mm
IC Package	COB
Display Type	FSTN /STN. Gray/Yellow-Green/Blue
Viewing Direction	6:00/12:00
Power Supply(Typ)	5.0V
Operating Temperature	-20℃~70℃
Storage Temperature	-30℃~80℃

Display Format	Model No.	Outline Dimension	Viewing Area	Active Area	IC	Interface
128 x 64	SDGB12864-01	54.00(W)x50.00(H)x8.00(T)mm	43.50x29.00mm	40.92x20.92mm	AIP310107 SBN0064	8-bit Parallel
128 x 32	SDGB12864-02	93.00(W)x70.00(H)x12.50(T)mm	72.00x39.00mm	66.52x33.24mm	AIP31107 SBN0064	8-bit Parallel
128 x 64	SDGB12864-03	78.00(W)x70.00(H)x12.50(T)mm	62.00x44.00mm	56.28x38.36mm	T6963 RA6963	8-bit Parallel
128 x 64	SDGB12864-04	93.00(W)x70.00(H)x12.50(T)mm	72.00x39.00mm	66.52x33.24mm	ST7920 AIP31020	8-bit Parallel
128 x 64	SDGB12864-05	78.00(W)x70.00(H)x12.50(T)mm	62.00x44.00mm	56.28x38.36mm	AIP31107 SBN0064	8-bit Parallel
128 x 64	SDGB12864-06	93.00(W)x70.00(H)x12.50(T)mm	72.00x39.00mm	66.52x33.24mm	T6963 RA6963	8-bit Parallel
128 x 64	SDGB12864-07	93.00(W)x70.00(H)x12.50(T)mm(T)mm	72.00x39.00mm	66.52x33.24mm	AIP31107 SNB0064	8-bit Parallel
128 x 64	SDGB12864-08	75.00(W)x52.60(H)x12.50(T)mm	60.00x32.50mm	655.01x27.49mm	AIP31107 SNB0064	8-bit Parallel
128 x 64	SDGB12864-09	93.00(W)x70.00(H)x12.50(T)mm	72.00x39.00mm	66.52x33.24mm	ST7920 AIP31020	8-bit Parallel
128 x 64	SDGB12864-10	93.00(W)x85.00 (H)x11.20(T)mm	72.00x39.00mm	66.52x33.24mm	AIP31020 ST7920	8-bit Parallel
