All the round tft display screen could be added circular touch screen, our circular touch display can be with multi-touch round screen, and with ips free viewing angle. The round screen could be widely used in many round display screen application, such as round screen in smart home-control, round tft display panel in audio device with full color display. and the color round tft display bring the amazing display effect to the end customer, after adding the muti-touch screen on the round tft display, end customer could control the device via the circular round touch screen from round tft lcd display. Our round tft display module are with high quality, and custom make round tft display is also welcome to us.
Availability:In Stock
| Manufacturer | SINDA |
| Part Number | SDGB12864-01 |
| Display Format | 128x64 dots |
| Interface | 8-bit Parallel |
| IC or Equivalent | AIP310107 SBN0064 |
| Connection | Pin Header |
| Outline Dimension | 54.00(W)x50.00(H)x8.00(T)mm |
| Visual Area | 43.50x29.00mm |
| Active Area | 40.92x20.92mm |
| Dot (Pixel) Size | 0.28x0.35mm |
| Dot (Pixel) Pitch | 0.32x0.39mm |
| IC Package | COB |
| Display Type | FSTN /STN. Gray/Yellow-Green/Blue |
| Viewing Direction | 6:00/12:00 |
| Power Supply(Typ) | 5.0V |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
| Display Format | Model No. | Outline Dimension | Viewing Area | Active Area | IC | Interface |
| 128 x 64 | SDGB12864-01 | 54.00(W)x50.00(H)x8.00(T)mm | 43.50x29.00mm | 40.92x20.92mm | AIP310107 SBN0064 | 8-bit Parallel |
| 128 x 32 | SDGB12864-02 | 93.00(W)x70.00(H)x12.50(T)mm | 72.00x39.00mm | 66.52x33.24mm | AIP31107 SBN0064 | 8-bit Parallel |
| 128 x 64 | SDGB12864-03 | 78.00(W)x70.00(H)x12.50(T)mm | 62.00x44.00mm | 56.28x38.36mm | T6963 RA6963 | 8-bit Parallel |
| 128 x 64 | SDGB12864-04 | 93.00(W)x70.00(H)x12.50(T)mm | 72.00x39.00mm | 66.52x33.24mm | ST7920 AIP31020 | 8-bit Parallel |
| 128 x 64 | SDGB12864-05 | 78.00(W)x70.00(H)x12.50(T)mm | 62.00x44.00mm | 56.28x38.36mm | AIP31107 SBN0064 | 8-bit Parallel |
| 128 x 64 | SDGB12864-06 | 93.00(W)x70.00(H)x12.50(T)mm | 72.00x39.00mm | 66.52x33.24mm | T6963 RA6963 | 8-bit Parallel |
| 128 x 64 | SDGB12864-07 | 93.00(W)x70.00(H)x12.50(T)mm(T)mm | 72.00x39.00mm | 66.52x33.24mm | AIP31107 SNB0064 | 8-bit Parallel |
| 128 x 64 | SDGB12864-08 | 75.00(W)x52.60(H)x12.50(T)mm | 60.00x32.50mm | 655.01x27.49mm | AIP31107 SNB0064 | 8-bit Parallel |
| 128 x 64 | SDGB12864-09 | 93.00(W)x70.00(H)x12.50(T)mm | 72.00x39.00mm | 66.52x33.24mm | ST7920 AIP31020 | 8-bit Parallel |
| 128 x 64 | SDGB12864-10 | 93.00(W)x85.00 (H)x11.20(T)mm | 72.00x39.00mm | 66.52x33.24mm | AIP31020 ST7920 | 8-bit Parallel |
